Integrated Digital Seismometer

Release time:2025/3/27 11:49:25popularity:

Frequency bandwidth5s-250Hz10s-250Hz20s-200Hz60s-100Hz120s-100Hz

Channelsorthogonal three-channel

Dynamic range:≥120db

Complete machine sensitivity:≥500V/m/s(Tolerance better than ±5%)

Time stability5x10-7sbuilt-in BD+GNSS positioning timing

Sample rate5010020050010002000sps

Continuous operating hours (autonomous power self-sustainability): >45 days  (@25/ 100sps/in autonomous operating mode), support external power supply to extend the working time

Self-calibration mode: pulse self-calibration

Status display: LED+LCD

Interactive platform: Windows, Android, Linux

Data format: MiniSEED, Raw (can be converted to SAC and many other formats)

Data download: USB, plug-in TF card, Ethernet, WIFI, 4G (optional)

Real-time data streaming service: support multi-terminal network real-time transmission of data streams(maximum 5 clients)

Real-time data stream output delay: 1s

Remote control: support remote receive restart command and automatically complete the restart of the instrument

Interaction Interface:RS232,Ethernet, WIFI, 4G(optional)

Induction identification: RFID electronic tags

Working angle: ±5°;

Operating temperature: -25℃~+55℃;

Waterproof depth: 1m

Size (full-size):≤152mm*152mm*240mm

Weight:≤6Kg.
